Colloid Mill

Colloid Mill

Features

  • High Efficiency Commercial Peanut Butter Colloid Mill Machine For Food
  • Colloid Mill features excellent breaking,emulsifying, homogenous and uniform mixing capability. For most solid materials, their grinding particles can reach diameters of three micrometers and homogenous rates of above 90%, which make the colloid mill an ideal processing facility for ultrafine particles. The machine can perform similar machinery tasks of homogenous machine, ball mill, three-roller polishing machine, agitator and plasm-grinding machine.


Product Description

  • Major spare parts of the colloid mill are made of high quality stainless steel and free from corrosion and poison.
  • The major working parts, rotator and stator, are made by advanced technology and excellent processing. The adjusting ring, with the measuring scales on it, it's easy to read, use and can make micro-adjustments between the spaces so as to ensure the quality of products. According to different raw material, rotators and stators made of various ingredients are available in our company. They are all easy to disassemble and clean


Competitive advantage

  • Colloid mill economic equipment to process colloid
  • Homogenous rate more than 90%.
  • Meet the GMP standard
  • All parts contacting the material are made of stainless steel
  • Cooling type: Water-cool


Technical Specification

Name

Standing colloid mill

Variable speed colloid mill

Type

JM-80(J)

JM-130(J)

JMS-50

JMS-80

JMS-130

Material processing size (µm) (single cycle or multi-cycle)

2-50

2-50

2-50

2-50

2-50

Capacity (t/h) (change with the nature of material

0.07-0.5

0.5-2

0.005-0.03

0.007-0.5

0.5-2

Power of main electrical motor (kw)

4

11

1.1

4

11

rpm of electrical motor (r/min.)

2890

2930

1750-5000

1600-5000

1750-5000

Overall size (LxWxH) mm

45*46*133

55*55*140

53*26*58

68*38*93

99*44*105

Gross weight (kg)

190

320

70

210

420
